CNC DYNAMICS PLUS with Multi spindle and Multi toolchanger

Any size table, any spindle configuration.

Our high production CNC Router
For the machining of multiple components in parallel but retaining the ability to cut nested sheets
Dynamics Plus digital CNC and servo system
CadCam ready
Multiple stop location, pod location system
  • Router spindle. HSD 9kw 24000rpm with ISO30 or HSK63F toolholding.

  • Syntec CNC system. High performance absolute drive system with advanced algorithms for high speed interpolation.

  • Increased mechanical rigidity. Enhanced gear ratios for high accuracy positioning.
  • On screen component real time graphics
X-Axis Travel 2440mm
Y-Axis Travel 1220mm
Z-Axis Travel 200mm
Table Size Customer can specify bed size
Feed Rate X-Axis 0-40m/min
Feed Rate Y-Axis 0-40m/min
Rapid X/Y Axes 0-80m/min
