CNC DYNAMICS Evo 1515

High-Performance Industrial 5×5 CNC Router

The CNC Dynamics EVO 1515 is a high-performance industrial CNC router engineered for advanced machining applications. Designed for manufacturers working with composites, engineered plastics and demanding materials, the EVO platform delivers exceptional speed, precision and reliability across a wide range of routing operations.

Engineered and supported by CNC Support, the EVO range is trusted by manufacturers across industries including aerospace supply chains, plastics fabrication, composite manufacturing and specialist engineering.

Key Features of the CNC Evolution 1515

Industrial CNC Router for Composites, Engineering Plastics and Advanced Manufacturing

  • Working area: X-axis 1600 mm × Y-axis 1600 mm × Z-axis 300 mm

  • 9 kW HSD automatic tool-change spindle with gantry-mounted 12-station tool magazine

  • Programmable spindle speeds up to 24,000 rpm for a variety of materials

  • Flat matrix vacuum table with configurable zones for secure material hold-down

  • Automatic tool length setting for quick, accurate setup

  • High feed rates up to 40 m/min and rapid traverse speeds up to 60 m/min

  • Safety light beam system for operator protection

  • Fully UKCA Compliant – Full guidance can be found here.

Engineered for High-Performance CNC Routing

The EVO range has been developed for manufacturers requiring greater machining capability, higher precision and advanced control functionality.

Features such as the heavy-duty structure, precision motion system and powerful spindle technology enable the EVO 1515 to maintain consistent accuracy even during demanding machining operations.

Combined with the latest CNC control technology, the machine offers excellent speed, repeatability and production reliability.

Applications & Materials

The EVO 1515 CNC router is widely used across industries including:

• Aerospace component machining

• Composite panel fabrication

• Plastic fabrication and engineering plastics machining

• Architectural cladding panel machining

• Industrial component manufacture

• Signage and display manufacturing

The CNC Dynamics EVO 1515 is engineered for precision machining across a wide range of materials, including:

• Carbon fibre composites

• Glass fibre composites

• Engineered plastics

• Acrylic and polymer sheets

• Phenolic materials

• Aluminium composite panels

• Calcium silicate boards

• Wood-based panels and laminates

Its robust mechanical design and advanced spindle technology allow manufacturers to machine demanding materials with unrivalled accuracy and finish quality.

Installation, Training, and Support Included

When you invest in the CNC Evolution 1515, you get more than just a machine – you get full UK-based installation, commissioning, and operator training from our experienced in-house engineers at CNC Support Ltd. See more about our service and support offering here.

We provide ongoing technical support via phone, email, and remote login, plus optional preventative maintenance agreements to keep your CNC router performing at its best.

FAQ’S:

The machine is designed for standard 5×5 sheet material, making it suitable for a wide range of manufacturing applications.

Industries include aerospace, plastics fabrication, composite manufacturing, signage and specialist engineering.

Yes. The machine is specifically engineered to machine demanding materials including carbon fibre, glass fibre composites and engineering plastics.

Training delivered with every EVO router is fully tailored to your application, materials and production requirements.

We do not deliver generic, time-limited demonstrations. Instead, our engineers work directly with your team to program and machine the components you actually produce – ensuring real-world understanding and immediate production relevance.

The CNC Dynamics CDS and EVO ranges are designed for different production requirements and are equally heavy-duty and capable.

The CDS range provides reliable, production-focused CNC routing for a wide variety of materials including wood-based panels, plastics and general manufacturing applications.

The EVO range represents the high-performance tier of CNC Dynamics routers, engineered for manufacturers working with more demanding materials and machining processes. EVO machines are commonly used for applications involving composites, engineering plastics and advanced industrial components, where higher machining performance, enhanced control functionality and advanced production features are required.

Both ranges are fully supported by the engineering team at CNC Support, ensuring customers receive expert installation, training and long-term service support.

The numbers used in our CNC Dynamics names refer to the working area of the machine. A 1515 CNC router indicates a machining area of approximately 1600mm × 1600mm, making it ideal for processing standard 5×5 sheet material used across many manufacturing industries.

Specifications

X-Axis Travel 1600mm
Y-Axis Travel 1600mm
Z-Axis Travel 300mm
Table Size 1560 x 1560
Feed Rate X-Axis 0-40m/min
Feed Rate Y-Axis 0-40m/min
Rapid X/Y Axes 0-60m/min
